25' Sea Bird Yawl

A simple and seaworthy V-bottomed centerboard cruiser with accommodations for two.

Designed by Charles G. MacGregor

LOA - 25' 7"
LWL - 20' 3"
Beam - 8' 1"
Draft (cb up) - 2' 6"
(cb down) - 4' 0"
Displ. - 4,313 lbs.
Sail Area - 379 sq. ft.
Construction: Plywood planking over sawn frames
Lofting is required
Skill level: Intermediate
Plans include 10 sheets, plus 1 page of additional notes from the designer.

More info: click MATERIALS LIST.
