Wittholz 35' Departure Class

An oceangoing V-bottomed auxiliary (35hp) with accommodations for four to six people that may be built carvel style or with plywood.

Designed by Charles Wittholz

LOA - 35'
LWL - 27' 10"
Beam - 10' 5"
Draft - 4' 3" to 5'
Displ. - 15,300 lbs.
Sail Area :
Sloop - 580 sq. ft.
Cutter - 658 sq. ft.
Ketch - 705 sq. ft.
Construction: Carvel planked over sawn frames
Alternative construction: Plywood (plans included)
Lofting is required
Skill level: Advanced
Plans include 15 sheets, plus 7 pages of additional notes from the designer.



MORE INFO ON THIS DESIGN:

35' Departure Class was featured in Boat Design Quarterly #40.
